T&S Brass EC-3102 Deck Mount ChekPoint Electronic Faucet

Description

Being electronic activated, this T&S Brass EC-3102 is ideal for handwashing stations and commercial restrooms or rest areas. It has a solid cast brass spout, polished and chrome plated for increased durability and an attractive appearance. It has a 2.2 GPM vandal resistant aerator and a removable strainer. It has a 2″ deep, water resistant control box that can be AC or DC operated. The control box uses four AA batteries and is operated with internal flow control switches. This EC-3102 has a temperature mixing valve with integral check valves.

Features and Benefits:

• Solid Cast Brass Spout
• Polish Chrome Plated Finish
• 2.2 GPM [8.3L/min] Vandal Resistant Aerator
• 3-5/8″ x 4-3/16″ x 2″ Deep Water Resistant Control Module Box (Blue)
• Internal Flow Control Setting Switches
• AC or DC Operated
• (4) AA Batteries
• Hardwire Capable Using Terminals on Back
• 24″ [610 mm] Sensor Cable
• Removable Strainer
• 1/2″ NPSM x 1/4″ NPSM 18″ [457 mm] Long Flexible Stainless Steel Hose
• Temperature Mixing Valve with Integral Check Valves
• 100-240 VAC Adapter with 144″ [3658 mm] Long Double Power Cord
• (Remove Rubber Plugs on Module and Cable to Connect)
• (2) 3/8″ Compression x 1/2″ NPSM 18″ [457 mm] Flexible Stainless Steel Supply Hose
• 1/8″ [3 mm] Anti-rotation Pin. Remove Pin if Desired

Specifications:

• Model: EC-3102
• Approximate Weight: 6.7 lbs.
